Specifications

• Frame
  • Frame

    FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry | 145mm Travel | FORM™ Alloy Rear Triangle

  • HeadsetFSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
  • Fork

    RockShox Lyrik Select 150mm | Charger RC Damper | 27.5 = 37mm Offset | 29 = 42mm Offset

  • Rear Shock

    SM-XL: Rock Shox Super Deluxe Select | 230x57.5mm | XS: Rock Shox Deluxe Select+ | 210x52.5mm | Sealed Bearing Eyelet | 25x8mm F Hardware | Size-Specific tune in FAQ

• Drivetrain
  • Crankset

    Race Face Turbine Cinch | 34T Ring | 30mm Spindle | XS - XL = 165mm

  • Cassette

    Shimano Deore 10-51T 12spd

  • ChainShimano M6100
  • Rear DerailleurShimano XT
  • ShiftersShimano XT
• Brakes
  • Brakes

    Shimano MT6120 4 Piston | Metal Pads

• Components
  • Handlebar

    Rocky Mountain AM | 780mmWidth | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp

  • GripsODI Elite Pro Lock On
  • Stem

    Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm

  • Seatpost

    X Fusion Manic Composite 30.9mm |XS - SM = 125mm | MD = 150mm | LG = 170mm | XL = 200mm

  • Saddle

    WTB Volt Race 142 | Cromoly rails

• Wheels
  • Rims

    WTB KOM Trail i30 TCS 2.0 | 28H | Tubeless Set Up | Sealant Incl

  • Front Hub

    Rocky Mountain SL Sealed Boost 15mm

  • Rear Hub

    Novatec MTB SL Pro Boost 148mm

  • SpokesDT Swiss Competition 2.0/1.8/2.0
  • Tires

    Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | Tubeless Set Up | Sealant Incl

• E-Bike
  • Battery

    480 Wh Removable Integrated Li-Ion

  • Charger

    Rocky Mountain Powerplay FAST Charger | 4A | 48V | Higo Deep Socket Connector
