Cadre
FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry + Suspension Rate | 160mm Travel. FORM™ Alloy Rear Triangle
Fourche
RockShox Domain RC 170mm | 44mm Offset
Débattement avant
170
Amortisseur
Marzocchi Bomber CR | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230x62.5mm | Size-Specific tune in FAQ
Débattement arrière
160mm
Jeu de direction
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Potence
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m
Cintre
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Poignets
Rocky Mountain Lock On Light
Freins
Shimano MT4120 4 Piston | Metal Pads | F:Shimano RT64 203mm | R:Shimano RT64 203mm
Commandes de vitesses
Shimano Deore 11spd
Derailleur arrière
Shimano Deore 11spd
Pédalier et plateau
Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM - MD = 165mm | LG - XL = 170mm
Boitier de pédalier
Shimano SM-BBMT500
Cassette
Shimano Deore 11-51T 11spd
Chaine
KMC X11-1
Moyeux avant
Rocky Mountain Sealed Boost 15mm
Moyeux arrière
Novatec D462 Sealed Boost 148mm
Rayons
2.0 Stainless
Jantes
WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl
Pneus
F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready
Tige de selle
Rocky Mountain Toonie Drop Composite 30.9mm | SM = 125mm | MD = 150mm | LG - XL = 170mm
Selle
WTB Volt 142
Drive System
Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada
Battery
720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A)
Remote
Rocky Mountain Micro Remote
Display
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration
Charger
Rocky Mountain Powerplay Charger | 2A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
Poids
This information isn't available yet. We will update the weight of this model as soon as possible.
Notes
We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
